Description
- CREE® XLamp XP-L HI undomed LEDs using CREE’s breakthrough SC5 Technology™
- RFI and EMI suppression circuit. Guaranteed to not interfere with Radio or GPS Equipment
- IP68 - Submersible to 3m
- High Current Deutsch DTP-2 25A connectors
- 32mm diameter parabolic reflectors
- Spread and Spot beam pattern
- 4mm thick 304 stainless steel side brackets included.
- Cast Alloy adjustable sliding bracket included.
- Nitto Denko™ Breather with PTFE microporous membrane
- Very heavy-duty Smart Plug & Play ADR compliant Wiring Harness. (Switch, Dual Fuse, Dual Relay and HB3 and H4 Piggyback Adaptors) included
LED MANUFACTURER | CREE XPL Hi |
LED COUNT | 40 |
VOLTAGE | 9V - 32V |
CURRENT DRAW (AMPERES) | 25.3a @13.6v |
LENS MATERIAL | OPTICAL GRADE, HARD COATED LEXAN |
RAW LUMENS | 43,800Lm |
EFFECTIVE LUMENS | 22,400Lm |
PEAK INTENSITY (CANDELA) | 656,100cd |
HOUSING MATERIAL | A360.0 Cast face plate, extruded Aluminum heat sink |
LIFESPAN | 50,000 |
FLOOD BEAM | 50° |
SPOT BEAM | 9° |
INGRESS PROTECTION | IP68 |
OPERATING TEMP | -40˚C ~ +150˚C |
WEIGHT | 4.960kg |
